Rebar End Upsetting Machine – Dies & Setup

Hydraulic TMT Bar Forging Machine by Industrial Machinery Corporation
PRICE & QUOTATION
Starting From US$ 6,000
Choose options
Set quantity
Request quotation

Select the required model and specifications to request your quotation.

Review Rebar End Upsetting Machine for your component and the required production operation.

Start with the tooling interface

To upset suitable reinforcement-bar ends hydraulically as preparation for the specified coupler-thread process, the proposed machine and tooling must suit the complete component requirement. Review forging dies, end location, clamping and the supplied hydraulic configuration. Existing tools should be identified by model, dimensions or a sample rather than only a familiar name.

Set up around the finished drawing

Provide bar grade and diameter, original end geometry and required forged-end drawing. Discuss how the component is presented and what adjustments are required when a size changes. End forging does not itself produce the thread; confirm the complete preparation and threading route for the coupler system. Ask which fixtures or tool sets are included for the initial job and whether the remaining sizes need additional equipment.

Verify the trial and specify the offer

Check a representative result for forged-end dimensions and the condition needed for the following threading stage. Identify the measurement or inspection requirements with the drawing. A trial should use the intended material and stock condition so that setup decisions apply to the real job. Include batch quantities, site utilities and delivery details with the selected quotation options. The offer should state the model, tooling, accessories and changeover arrangements against those requirements.

Information to send with your enquiry

  • Bar grade and diameter
  • Original end geometry and required forged-end drawing

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.

VIEW SPECIFICATIONS

Tags

TMT Bar Forging Machine
CONFIGURE YOUR MACHINE

Available options

Select the required options and add this machine to your quotation.

Available Options


Your selected configuration is stored in the existing Quote List flow for review before enquiry.

Product Videos

View full playlist on YouTube
TECHNICAL DATA

Technical Specifications

Model data and technical details supplied for this product. Final configuration can be confirmed against your application.

TMT Bar Forging Machine

A TMT (Thermo-Mechanically Treated) bar forging machine is a specialized equipment used in the manufacturing process of TMT bars, which are commonly used in construction projects for their high strength and durability.

The TMT bar forging machine is designed to deform and shape metal billets or ingots into TMT bars through a forging process. The machine utilizes high-pressure mechanical force to compress and shape the metal, resulting in the desired cross-sectional shape and dimensions for the TMT bars.

The typical steps involved in the TMT bar forging process are as follows:

Heating: The metal billets or ingots are heated to a specific temperature, usually above the recrystallization temperature, to make them malleable for forging.

Pre-forging: The heated billet is placed in the forging machine, where it undergoes initial shaping and reduction of its cross-sectional area. This step prepares the billet for the final forging process.

Final forging: The pre-forged billet is further processed under high-pressure forging to achieve the desired shape and dimensions of the TMT bar. The machine applies force to compress and elongate the metal, gradually forming it into the desired bar shape.

Cooling: After the forging process, the formed TMT bars are cooled to room temperature gradually to relieve any internal stresses and improve their mechanical properties.

Post-processing: The forged TMT bars may undergo additional processes such as straightening, cutting, and surface treatment to meet the required specifications.

TMT bar forging machines are typically heavy-duty equipment that can handle large volumes of metal and are designed to withstand the high forces involved in the forging process. They often incorporate advanced automation and control systems to ensure precise shaping and dimensional accuracy of the TMT bars.

It's worth noting that specific machine designs and configurations may vary depending on the manufacturer and the desired output capacity.

Frequently Asked Questions About Hydraulic TMT Bar Forging Machine

Please identify bar grade and the prepared-end drawing. Add the finished drawing, expected batch size and available electrical supply. IMC can then discuss the model and the supporting equipment for that particular job.

Agree the configuration against bar grade and the prepared-end drawing, then confirm the tooling, workholding and accessories included. Any support, installation or spare-tool needs should be listed with the enquiry so the scope is clear.

Use the specifications and demonstration videos alongside your current component drawing. Record bar grade and the prepared-end drawing, the stages before and after this operation, and your desired output; that comparison gives IMC a useful basis for reviewing the change.
