Model data and technical details supplied for this product. Final configuration can be confirmed against your application.
The name of Industrial Machinery Corporation is ranked in top ten manufacturers and exporters of industrial machines owing to its best quality machines that we have manufactured which are popular all over the world. We have been in the business of production and export of industrial machines for more than a decade now and have all the knowledge that is required to be the top manufacturer and exporter. Industrial Machinery Corporation has gained a huge name as an expert in manufacturing thread cutting machines and this is true too, as we truly have the best team and set-up to manufacture pipe threading machines. One of the best known threading machines that we make here is PVC Pipe Threading Machine. We make these Machines with utmost care and considering all the types of job, the user would want to accomplish using it. As with our all pipe threading machines, this PVC Pipe Threading Machine too is built to generate the most precise and accurate results of pipe threading and this is the reason why our PVC Pipe Threading Machine is arguably the best in all the PVC Pipe Threading Machines present in the market. Our Machines is designed and programmed to give the best and most precise results even while working in the most severe environment. It has a specially designed lathe which has the potential to thread the pipe of various sizes ranging from 50 M.M to 250 M.M for a 3 to 4-meter pipe. The new and advanced designed collets system has been given in these PVC Pipe Thread Cutting Machines which allows quick uploading and downloading of PVC pipe for threading purposes. This system allows this PVC Pipe Thread cutting Machine to perform the pipe thread cutting action at a very rapid speed. The main USP of our Machines is that it is geared with double sided saddle system which makes two users work mutually on this PVC Pipe Threading Machine this ease of two workers working together can increase the speed of the manufacturing process as two people can thread the pipe from in and out in a single time.
The raw material that we use to manufacture our PVC Pipe Threading Machines is the best chosen by our quality checking team as this team has been constituted particularly for assessing the quality of the raw material coming in and the finished product ready for delivery. This team carefully assesses all the raw materials and makes sure that only the best quality raw material is used for the manufacture of our PVC Pipe Threading Machines. This assures us of the quality of our finished items that it’ will always be of the topmost class. Following are the type of threads that can be created using a PVC Pipe Thread Cutting Machine.
| Model | 3/8" to 2" (10MM to 50MM) | 1/2" to 2.1/2" (12MM to 65MM) | 1" to 4" (25MM to 100MM) | 2.½" to 6" (65MM to 150MM) | 4" to 8" (100MM to 200MM) | 8" to 10" (200MM to 250MM) |
| Saddle Movement | 10"- 12" | 16" | 10“ - 12" | 8" | 8" | 8" |
| Spindle Speed Range | 127-180 | 60-90-120 | 40-75-115 | 25-50 | 25-50 | 10-20-30 |
| Number of Spindle Speed | 2 | 3 | 3 | 2 | 2 | 3 |
| Threading Capacity | 3/8" to 2" | 1/2" to 2.1/2" | 1 to 4" | 2.1/2" to 6" | 4" to 8" | 8" to 10" |
| Production per Hour | 100-120 | 70-90 | 35-40 | 20-25 | 15-20 | 15-20 |
| H.P. Required | 3 H.P. | 7.5 H.P. | 12.5 H.P. 960 | 15 H.P. 960 | 20 H.P. 960 | 30 H.P. 960 |
| Lead Screw | Provided | Provided | Provided | Provided | Provided | Provided |
| Weight (KG) Approx. | 550 | 990 | 1600 | 1900 | 2500 | 5000 |
PVC Pipe Threading Machine Tangential Chaser
IMC Tangential Chasers are manufactured from imported High-Speed Steel which must pass exacting metallurgical standard. Experienced heat treatment with the automatically imported heat treatment plan and imported Testing equipment, assure that they will perform satisfactorily in service and produce quality threads within the tolerance for which they ware intended.IMC Chaser is interchangeable. If one Pc. Of a chaser, a set is damaged & is beyond use. Then same No. pc. Of the other chaser set lying in stock may be used and there will not be any difference in threading performance and the damaged set can be replaced without the necessity of replacing the entire set.
Please identify PVC grade, wall thickness and joint drawing. Add the finished drawing, expected batch size and available electrical supply. IMC can then discuss the model and the supporting equipment for that particular job.
Agree the configuration against PVC grade, wall thickness and joint drawing, then confirm the tooling, workholding and accessories included. Any support, installation or spare-tool needs should be listed with the enquiry so the scope is clear.
Use the specifications and demonstration videos alongside your current component drawing. Record PVC grade, wall thickness and joint drawing, the stages before and after this operation, and your desired output; that comparison gives IMC a useful basis for reviewing the change.
Review Chaser Type PVC Pipe Threading Machine for your component and the required production operation. Start with the tooling interfaceTo cut external PVC pipe threads using a compatible Lanco type d ...
